DVR 16CH HDCVI PENTABRID AI/XVR5116HS-I3 DAHUA

  • ELKO kodas
    1365106
Pentabrid capability: Each channel supports up to 6MP: IP, HDCVI, AHD, TVI and CVBS access can be configured
16-channel BNC interface
Recording: HDCVI/AHD/HD-TVI recording:, 5MP, 4MP, 3MP, 2MP
All channel 5M-N (1 fps–10 fps); 4M-N/1080P (1 fps–15fps); 1080N/720P/960H/D1/CIF (1fps–25/30 fps)
IP: 16+8 channels, each channel up to 6MP, Max 128 Mbps incoming bandwidth
AI Coding/H.265+/H.265/H.264+/H.264 video compression
G.711A, G.711U, PCM audio compression,
1x SATA interface up to 16 TB storage
VGA/HDMI up to 4K output
RJ-45, 2x USB ports, RS485
No front panel control, 1/1 Audio I/O, no Alarm I/O, Audio over Coax for 8 channels
Mini 1U case, mouse included
ONVIF 16.12, CGI Conformant, Smart Search
Third-party IP camera support: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
AI: Up to 2 channels video stream (analog channel) Perimeter Protection
Up to 16 channels video stream (analog channel) SMD Plus
Up to 2 channels video stream (analog channel) human face recognition
IoT & POS functionalities
Free IP monitoring software available
  • CnCode
    85219000
  • DVR type
    8 Channel
  • Camera Compatibility
    Analog
  • Camera Compatibility
    IP
  • Camera Compatibility
    HDCVI 720P
  • Camera Compatibility
    HDCVI 1080P
  • Camera Compatibility
    HDCVI 4MP
  • Camera Compatibility
    HD-TVI/TurboHD 5MP
  • Camera Compatibility
    AHD 5MP
  • Camera Compatibility
    HDCVI 8MP
  • SATA
    Yes
  • USB
    Yes
  • 15pin D-sub
    1
  • Audio-In
    1
  • Audio-Out
    1
  • HDMI
    1
  • Power supply requirements
    DC12V, 2A
  • Dimensions
    260.0 mm × 237.4 mm × 47.6 mm
  • Shipping box quantity
    1
  • Shipping Box Width
    9cm
  • Shipping Box Depth
    33.5cm
  • Shipping Box Height
    31.5cm
  • Shipping Box Weight
    1.54kg
  • Unit Brutto Volume
    0.009497cubm
  • Unit Net Weight
    0.9kg
  • Unit Gross Weight
    1.54kg
